Resolution
Native 480p (854 x 480)
Maximum UXGA (1,600 x 1,200)
Brightness
800 Lumens (LED brightness),
220 ANSI Lumens (Standard),
40 ANSI Lumens (ECO, Battery)
Aspect ratio
16:9 (Native), 4:3 (Supported)
Colors
16.7 Million Colors
Projection Lens
F = 1.60, f = 5.02mm, Manual Focus
Projection Screen Size
29" ~ 100" (73 cm ~ 254cm)
Projection Distance
0.7m ~ 2.9m (2.30’ ~ 9.51’)
Keystone correction
+/-25° (Vertical, Manual & Auto),
+/-14° (Horizontal, Manual),
4-Corner adjustment
Lamp Life
20,000 Hours (Standard), 30,000 Hours (ECO)
Input Interface
HDMI (Video, Audio, HDCP) x 1
USB (Type A) x 1, share output port x 1
USB (Wireless dongle, Type A) x 1
Output Interface
DC Out (5V/0.5A, USB Type A) x 1
Headphone Out (Stereo mini jack) x 1
Dimensions (W x D x H)
115 x 115 x 36.3 mm (4.5"" x 4.5"" x 1.43"")(w/ feet)
Projection Mode
Front, Up, Auto Portrait Mode
Computer Compatibility
IBM PC and Compatibles and VESA Standards 1080p (1,920x1,080), WSXGA+ (1,680 x 1,050), WXGA+ (1,440 x 900), WXGA (1,366 x 768, 1,280 x 800, 1,280 x 768), UXGA (1,600 x 1,200), SXGA+ (1,400 x 1,050), SXGA (1,280 x 1,024), XGA (1,024 x 768), SVGA (800 x 600)
Power
DC input 15V via a 30W power adapter (AC input 100~240V, 50/60 Hz to DC 15V)
Battery Run time
5 Hours (ECO), 2 Hours (Standard)
Operation Temperature
N/A
Operation Humidity
80%RH (Max.)
Accessory (Standard)
AC to DC power adapter (1.5m)
Exchangeable plugs
Quick start guide
Pouch
WirelessProjection-Kit (UWA5)
IR Remote
HDMI cable
